DR-30W Din Rail Power Supply 24V, 1.5A

Product DR-30-24
Description DR-30W Din Rail Power Supply 24V, 1.5A
Make Xexagon
Certification CF
DC VOLTAGE 24V
RATED CURRENT 1.5A
CURRENT RANGE 0 ~ 1.5A
RATED POWER 36W
RIPPLE & NOISE (max.) 150mVp-p
VOLTAGE ADJ.RANGE 21.6 ~ 26.4V
VOLTAGE TOLERANCE ±1.0%
LINE REGULATION ±1.0%
LOAD REGULATION ±1.0%
SETUP, RISE TIME 100ms, 30ms/230VAC 100ms, 30ms/115VAC at full load
HOLD TIME(Typ.) 100ms/230VAC 30ms/115VAC at full load
VOLTAGE RANGE 85 ~ 264VAC 120 ~ 370VDC
FREQUENCY RANGE 47 ~ 63Hz
EFFICIENCY (Typ.) 83%
AC CURRENT 0.88A/115VAC 0.48A/230VAC
INRUSH CURRENT(max.) COLD START 15A/115VAC 30A/230VAC
OVERLOAD 105 ~ 160% rated output power Protection type : Constant current limiting,recovers automatically after fault condition is removed
OVER VOLTAGE 27.6 ~ 32.4V Protection type : Shut down o/p voltage,re-power on to recover
WORKING TEMP. -20 ~ +60ºC (Refer to output load derating curve)
WORKING HUMIDITY 20 ~ 90% RH non-condensing
STORAGE TEMP., HUMIDITY -20 ~ +85ºC , 10 ~ 95% RH
TEMP. COEFFICIENT ±0.03%/ºC (0 ~ 50ºC)
VIBRATION 10 ~ 500Hz, 2G 10min./1cycle, 60min. each along X, Y, Z axes

In Stock: 5.0

Stock: 5.0 Can Dispatch Immediately
Factory Lead Time: 15 Days
