DR-60W Din Rail Power Supply 24V,2.5A
Specifications
| DC VOLTAGE | 24V |
| RATED CURRENT | 2.5A |
| CURRENT RANGE | 0 ~ 2.5A |
| RATED POWER | 60W |
| RIPPLE & NOISE (max.) Note.2 | 150mVp-p |
| VOLTAGE ADJ.RANGE | 21.6 ~ 26.4V |
| VOLTAGE TOLERANCE Note.3 | ±1.0% |
| INE REGULATION | ±1.0% |
| LOAD REGULATION | ±1.0% |
| SETUP, RISE TIME | 100ms, 30ms/230VAC 200ms, 30ms/115VAC at full load |
| HOLD TIME(Typ.) | 100ms/230VAC 23ms/115VAC at full load |
| VOLTAGE RANGE | 88 ~ 264VAC 124 ~ 370VDC |
| FREQUENCY RANGE | 47 ~ 63Hz |
| EFFICIENCY (Typ.) | 84% |
| AC CURRENT | 1.2A/115VAC 0.8A/230VAC |
| INRUSH CURRENT(max.) | COLD START 18A/115VAC 36A/230VAC |
| OVERLOAD | 105 ~ 160% rated output power Protection type: Constant current limiting, recovers automatically after fault condition is removed |
| OVER VOLTAGE | 27.6 ~ 32.4V Protection type: Shut down o/p voltage, re-power on to recover |
| WORKING TEMP. | -20 ~ +60ºC |
| WORKING HUMIDITY | 20 ~ 90% RH non-condensing |
| STORAGE TEMP., HUMIDITY | -40 ~ +85ºC, 10 ~ 95% RH |
| TEMP. COEFFICIENT | ±0.03%/ºC (0 ~ 50ºC) |
| VIBRATION | 10 ~ 500Hz, 2G 10min./1cycle, 60min. each along X, Y, Z axes |
