DR-30W Din Rail Power Supply 5V, 3A
Specifications
| DC VOLTAGE | 5V |
| RATED CURRENT | 3A |
| CURRENT RANGE | 0 ~ 3A |
| RATED POWER | 15W |
| RIPPLE & NOISE (max.) | 80mVp-p |
| VOLTAGE ADJ.RANGE | 4.75 ~ 5.5V |
| VOLTAGE TOLERANCE | ±2.0% |
| LINE REGULATION | ±1.0% |
| LOAD REGULATION | ±1.0% |
| SETUP, RISE TIME | 100ms, 30ms/230VAC 100ms, 30ms/115VAC at full load |
| HOLD TIME(Typ.) | 100ms/230VAC 30ms/115VAC at full load |
| VOLTAGE RANGE | 85 ~ 264VAC 120 ~ 370VDC |
| FREQUENCY RANGE | 47 ~ 63Hz |
| EFFICIENCY (Typ.) | 74% |
| AC CURRENT | 0.88A/115VAC 0.48A/230VAC |
| INRUSH CURRENT(max.) | COLD START 15A/115VAC 30A/230VAC |
| OVERLOAD | 105 ~ 160% rated output power Protection type : Constant current limiting,recovers automatically after fault condition is removed |
| OVER VOLTAGE | 5.75 ~ 6.75V Protection type : Shut down o/p voltage,re-power on to recover |
| WORKING TEMP. | -20 ~ +60ºC (Refer to output load derating curve) |
| WORKING HUMIDITY | 20 ~ 90% RH non-condensing |
| STORAGE TEMP., HUMIDITY | -20 ~ +85ºC , 10 ~ 95% RH |
| TEMP. COEFFICIENT | ±0.03%/ºC (0 ~ 50ºC) |
| VIBRATION | 10 ~ 500Hz, 2G 10min./1cycle, 60min. each along X, Y, Z axes |
In Stock: 2.0
| Stock: | 2.0 Can Dispatch Immediately |
| Factory Lead Time: | 15 Days |
| Price: |
₹ 740.00 ₹ 740.00₹ 740.00 |
